TracStar® 618 Series 2 Fusion Machine Package
Couldn't load pickup availability
Use this text to encourage communication or promote sharing on social networks.
6" IPS - 18" OD (160mm - 450mm)
TracStar® 618 Series 2 is capable of fusing 6" IPS - 18" OD (160mm - 450mm). We currently have this unit in stock with High Force Cylinders and Manual Clamping.
The new TracStar 618 Series 2 has been completely redesigned based on feedback from the field. The Series 2 machines incorporate a new cowling design that aids in heat dissipation — while providing easier access for machine maintenance. An updated electrical system increases the circuit protection and a standard battery disconnect in now incorporated for easy lockout.
A Hydraulic Clamping kit is available for all TracStar 618 Series 2 models. Add HC to the end of the part number or select the Hydraulic Clamping option while customizing your machine package.
The TracStar 618 is also available as an Automated machine that guides the operator through each step of the fusion process.
This package includes fusion machine, facer, heater, insulated heater stand and lifting assembly.
Featured Parts and Accessories:
Specifications
| TracStar® 618 Series 2 | |
|---|---|
| Machine | 2,290 lbs (1,038.7 Kg) |
| 4-Jaw Carriage | 511 lbs (231.8 Kg) |
| 3-Jaw Carriage | 416 lbs (188.7 Kg) |
| Facer | 94 lbs (42.6 Kg) |
| 6" IPS - 12" DIPS Heater | 28 lbs (13 Kg) |
| 12" IPS - 18" OD Heater | 34 lbs (15.4 Kg) |
| Shipping Weight | 2,791 lbs (1,266 Kg) |
| TracStar® 618 Series 2 | |
|---|---|
| System Pressure | 2000 PSI (137.9 BAR) Max. |
| Hydraulic Reservoir Capacity | 8 Gallons (30.28 Liters) |
| TracStar® 618 Series 2 | |
|---|---|
| Engine Type | 20 HP Liquid Cooled |
| Fuel Type | Diesel |
| Fuel Tank Capacity | 5 Gallons (18.92 Liters) |
| Operational Tank Capacity | 8 Hours |
| Starting System | Electric |
| TracStar® 618 Series 2 | |
|---|---|
| Input | None, self-contained |
| AC Output | 120V & 240V, 60Hz, 15 Amp |
| Heater Power | 3000 Watt |
| Facer Power | Hydraulic |
| TracStar® 618 Series 2 | |
|---|---|
| Frame | Welded steel construction |
| Brake | Self-locking |
| TracStar® 618 Series 2 | |
|---|---|
| Tracked | Rubber crawler tracks |
| Transportation | Self-propelled |
| Vehicle Speed | 1.5 MPH max |
| Lifting | Lift points and lifting assembly |
TracStar® 618 Series 2
| Machine | Shipping Container | |
|---|---|---|
| Length | 97.2" (2,468.9 mm) | 90" (2,286 mm) |
| Width | 56.1" (1,424.9 mm) | 60" (1,524 mm) |
| Height | 53.1" (1,348.7 mm) | 63" (1,600 mm) |
View Spec Sheet
Downloads
TracStar 618 Series 2 Product Manual
